R1:

eth7 - ke Cloud Internet
eth0 - R2: eth0
eth6 - LAN (192.168.123.x/24)

R2:

eth0 - R1: eth0
eth6 - LAN (192.168.124.x/24)


R1:

vtysh

configure terminal
interface eth0
  ip address 172.16.1.1/30
  exit
ip route 192.168.124.0 255.255.255.0 172.16.1.2
exit

R2:

vtysh

config terminal
interface eth0
  ip address 172.16.1.2/30
  exit
ip route 192.168.123.0 255.255.255.0 172.16.1.1
ip route 0.0.0.0 0.0.0.0 172.16.1.1
exit

Test

R1:

ping 192.168.2.1

R2:

ping 192.168.1.1


Setting Client

LAN 1 Client:

ip 192.168.1.2
gw 192.168.1.1


LAN 2 Client:

ip 192.168.2.2
gw 192.168.2.1
