Mikrotik: BGP Dua Link main backup - dengan as-path PREPEND

From OnnoWiki
Jump to: navigation, search

Ada tiga (3) ISP

ISP1:

IP 192.168.1.1/24 menuju ISP3
IP 192.168.3.1/24 menuju ISP2
AS 10
IP 10.100.100.0/24
IP 10.100.200.0/24

ISP2

IP 192.168.2.1/24 - menuju ISP3
IP 192.168.3.2/24 - menuju ISP1
AS 20
IP 10.10.10.0/24
IP 10.10.20.0/24

ISP3 (kita)

IP 192.168.1.2/24 - menuju ISP1
IP 192.168.2.2/24 - menuju ISP2
AS 30
IP 10.1.1.0/24
IP 10.1.2.0/24


Sambungan Fisik

ISP1 e0 -> ISP3 e0
ISP1 e1 -> ISP2 e1
ISP2 e0 -> ISP3 e1

ISP1 e2 10.100.100.1/24
ISP1 e3 10.100.200.1/24

ISP2 e2 10.10.10.1/24
ISP2 e3 10.10.20.1/24

ISP3 e2 10.1.1.1/24
ISP3 e3 10.1.2.1/24


Setup connection

ISP1

/ip address add address=192.168.1.1/24 interface=ether1
/ip address add address=192.168.3.1/24 interface=ether2
/ip address add address=10.100.100.1/24 interface=ether3
/ip address add address=10.100.200.1/24 interface=ether4

ISP2

/ip address add address=192.168.2.1/24 interface=ether1
/ip address add address=192.168.3.2/24 interface=ether2
/ip address add address=10.10.10.1/24 interface=ether3
/ip address add address=10.10.20.1/24 interface=ether4

ISP3

/ip address add address=192.168.1.2/24 interface=ether1
/ip address add address=192.168.2.2/24 interface=ether2
/ip address add address=10.1.1.1/24 interface=ether3
/ip address add address=10.1.2.1/24 interface=ether4

BGP Peering

Consider that IP connectivity between ISPs edge routers and Our Core router is already set up and working properly. So we can start to establish BGP peering to both ISPs.


ISP1:

#set our AS number
/routing bgp instance set default as=10
#add BGP peers
/routing bgp peer
add name=toISP2 remote-address=192.168.3.2 remote-as=20
add name=toISP3 remote-address=192.168.1.2 remote-as=30
# jika ingin redistribute default route ke client yang spesifik
# add name=toISP2 remote-address=192.168.3.2 remote-as=20 default-originate=if-installed
# add name=toISP3 remote-address=192.168.1.2 remote-as=30 default-originate=if-installed
#
# advertize routing
#
/routing bgp network
add network=10.100.100.0/24 synchronize=no
add network=10.100.200.0/24 synchronize=no

ISP2:

#set our AS number
/routing bgp instance set default as=20
#add BGP peers
/routing bgp peer
add name=toISP1 remote-address=192.168.3.1 remote-as=10
add name=toISP3 remote-address=192.168.2.2 remote-as=30
#
# advertize routing
#
/routing bgp network
add network=10.10.10.0/24 synchronize=no
add network=10.10.20.0/24 synchronize=no

ISP3:

#set our AS number
/routing bgp instance set default as=30
#add BGP peers
/routing bgp peer
add name=toISP1 remote-address=192.168.1.1 remote-as=10
add name=toISP2 remote-address=192.168.2.1 remote-as=20
#
# advertize routing
#
/routing bgp network
add network=10.1.1.0/24 synchronize=no
add network=10.1.2.0/24 synchronize=no

Main/Backup link setup

ISP3

Lakukan

  • accept network kita sendiri
  • drop semua tabel IP lainnya, karena kita tidak mau menjadi transit provider
  • BGP AS prepend - menaikan AS path
# setup routing filter
#
/routing bgp peer
set toISP1 in-filter=isp1-in out-filter=isp1-out
set toISP2 in-filter=isp2-in out-filter=isp2-out
#
# Outgoing filter ke ISP1:
#
/routing filter
#accept our networks
add chain=isp1-out prefix=10.1.1.0/24 action=accept
add chain=isp1-out prefix=10.1.2.0/24 action=accept
#discard the rest
add chain=isp1-out action=discard
#
# Outgoing filter ke ISP2:
#
/routing filter
#accept our networks and prepend AS path three times
add chain=isp2-out prefix=10.1.1.0/24 action=accept set-bgp-prepend=3
add chain=isp2-out prefix=10.1.2.0/24 action=accept set-bgp-prepend=3
#discard the rest
add chain=isp2-out action=discard
#
# ISP1 menjadi main
# ISP2 menjadi backup
#
/routing filter
add chain=isp1-in action=discard
add chain=isp2-in action=discard
#
/ip route
add gateway=192.168.1.1 check-gateway=ping
add gateway=192.168.2.1 distance=30 check-gateway=ping


Load sharing setup

Teknik melakukan multihoming / download sharing


ISP3

Disini salah satu network kita di prepend yang berbeda antara ISP1 dan ISP2

# Outgoing filter ke ISP1:
#
/routing filter
#accept our networks and prepend second network
add chain=isp1-out prefix=10.1.1.0/24 action=accept
add chain=isp1-out prefix=10.1.2.0/24 action=accept  set-bgp-prepend=3
#discard the rest
add chain=isp1-out action=discard
#
# Outgoing filter ke ISP2:
#
/routing filter
#accept our networks and prepend first network
add chain=isp2-out prefix=10.1.1.0/24 action=accept set-bgp-prepend=3
add chain=isp2-out prefix=10.1.2.0/24 action=accept
#discard the rest
add chain=isp2-out action=discard

Konfigurasi di atas hanya untuk outgoing packet dari network kita. Ada beberapa pilihan,

  • biarkan gateway menggunakan konfigurasi main/backup - ini akan menyebabkan hanya satu link yang digunakan dan routing akan asymetric.
  • gunakan policy routing untuk memaksa outgoing packet menggunakan link yang sama dengan dengan incoming
  • Menggnakan BGP untuk menerima full routing table dari ke dua peer dan menggunakan BGP attribute untuk melakukan routing melalui satu sambungan / link dan sebagian lagi melalui link lainnya. Contoh, traffic local / nasional bisa dikirim menggunakan ISP1 dan Internasional menggunakan ISP2.
